Double Twisted Gabion Basket Coastal Erosion Control Saltwater Resistance Heavy Duty

Brand Name : KN

Model Number : KN-gabion basket

Certification : CE ISO SGS COC PVOC

Place of Origin : CN

MOQ : 100 pc

Price : USD 12-17

Payment Terms : L/C, T/T, Western Union, MoneyGram

Supply Ability : 500 pc per day

Delivery Time : 15 work days

Packaging Details : pallet

Product Name : Double Twisted Gabion Basket Coastal Erosion Control Saltwater Resistance Heavy Duty

Key Words : Gabion Basket

Design Style : Industrial, CLASSIC, Modern

Zinc_Coating : 240g/m2

Processing Service : Bending, Custom Sizes

Lacing_Wire : 2.2mm

Gabion Basket Size : 1*1*1m, 2*1*1m, 3*1*1m, 4*1*1m

Picket : 25*25

Mesh_Type : hexagonal

Application : erosion control, retaining walls, landscaping, etc.

Contact Now

Double Twisted Gabion Basket Coastal Erosion Control Saltwater Resistance Heavy Duty

Woven Gabion Baskets for Hydraulic Protection

Designed for critical water management projects, our heavy-duty woven gabion baskets feature double-twisted hexagonal mesh made from 2.7-4.0mm galvanized or PVC-coated steel wire, offering exceptional strength (≥50kN/m) and durability. The 80×100mm mesh size optimally retains stone fill while maintaining 90%+ permeability for efficient water flow. Ideal for riverbank stabilization, flood control, and coastal protection, these baskets reduce flow velocity by 30-50% and accommodate ground settlement. Eco-friendly and long-lasting (25+ years), they provide reliable erosion control with minimal maintenance. Custom configurations available for large-scale hydraulic engineering solutions.

Key Features

  • Material: Hot-dip galvanized steel (Zn ≥ 250g/m²), PVC-coated options (0.5mm thickness)
  • Design: Hexagonal double-twist mesh, 90x110mm standard apertures (customizable)
  • Coatings: Epoxy/Zinc-Aluminum alloy for marine/coastal applications
  • Fillers: Crushed rock, recycled concrete, or vegetated soil (client-specified)

Technical Advantages
✓ 3x Lifespan: 50-100 years corrosion resistance
✓ Load Capacity: Up to 50kN/m² vertical pressure
✓ Eco-Friendly: 100% recyclable materials with zero chemical runoff
✓ Modular Assembly: Interlocking panels for 70% faster installation

Applications

  • Civil Engineering: Riverbank stabilization, highway embankments
  • Architecture: Retaining walls, sound barriers, decorative façades
  • Disaster Prevention: Flood control barriers, landslide mitigation systems
  • Mining: Tailings dam reinforcement, slope retention

Customization Services

  • Sizes: 2x1x1m (standard) up to 6x2x1m (heavy-duty)
  • Wire Diameters: 2.2mm – 4.0mm (3.0mm recommended for high-load zones)
  • Colors: Metallic Silver (standard), Green/Black PVC coating (urban projects)
gabion specifications Mesh hole modle
8x10cm 6x8cm
Length(m) Width(m) Height(m) Galvanized or PVC coated Galvanized or PVC coated
Mesh diameter Zinc Mesh diameter Zinc
2 1 1 2.7mm >245g/m² 2.0mm >215g/m²
3 1 1 Side wire diameter Zinc Side wire diameter Zinc
4 1 1 3.4mm >265g/² 2.7mm >245g/m²
6 1 1 Binding wire diameter of 2.7m Binding wire diameter of 2.0m
