ASTM Galvanized Gabion Wire Mesh For Erosion Control CE / ISO Certified

Brand Name : KN

Model Number : KN-gabion

Certification : CE ISO SGS COC PVOC

Place of Origin : CN

MOQ : 100 pc

Price : USD 14-19

Payment Terms : L/C, T/T, Western Union, MoneyGram

Supply Ability : 500 pc per day

Delivery Time : 15 work days

Packaging Details : pallet

Product Name : ASTM Galvanized Gabion Wire Mesh For Erosion Control CE/ISO Certified

Key Words : Gabion Wire Mesh

Wire Dia : 2.7mm

Weaving Type : double twist weaving

Metal Type : Iron

Surface Treatment : electro galvanized

Mesh Size : 60x80 80x100 80x120 100x120

Connect Way : by Helical wire, by U post, H post

Contact Now

ASTM Galvanized Gabion Wire Mesh For Erosion Control CE/ISO Certified

Product Overview

Hexagonal galvanized steel mesh structure (ASTM A975) for erosion control & retaining walls. Hot-dip Zn/Al coating (200g/m²) ensures 50+ years lifespan. Modular design allows rapid DIY assembly. Used in flood barriers , mining, highways. Permeable & eco-friendly with stone/vegetation fill. Sizes: 2x1x1m to 6x2x1m. CE/ISO certified.

Key Features

Material: Hot-dip galvanized steel (Zn ≥ 250g/m²), PVC-coated options (0.5mm thickness)
Design: Hexagonal double-twist mesh, 90x110mm standard apertures (customizable)
Coatings: Epoxy/Zinc-Aluminum alloy for marine/coastal applications
Fillers: Crushed rock, recycled concrete, or vegetated soil (client-specified)

Technical Advantages
✓ 3x Lifespan: 50-100 years corrosion resistance
✓ Load Capacity: Up to 50kN/m² vertical pressure
✓ Eco-Friendly: 100% recyclable materials with zero chemical runoff
✓ Modular Assembly: Interlocking panels for 70% faster installation

Applications

Civil Engineering: Riverbank stabilization, highway embankments
Architecture: Retaining walls, sound barriers, decorative façades
Disaster Prevention: Flood control barriers, landslide mitigation systems
Mining: Tailings dam reinforcement, slope retention

Customization Services

Sizes: 2x1x1m (standard) up to 6x2x1m (heavy-duty)
Wire Diameters: 2.2mm – 4.0mm (3.0mm recommended for high-load zones)
Colors: Metallic Silver (standard), Green/Black PVC coating (urban projects)

gabion specifications			Mesh hole modle
			8x10cm		6x8cm
Length(m)	Width(m)	Height(m)	Galvanized or PVC coated		Galvanized or PVC coated
			Mesh diameter	Zinc	Mesh diameter	Zinc
2	1	1	2.7mm	>245g/m²	2.0mm	>215g/m²
3	1	1	Side wire diameter	Zinc	Side wire diameter	Zinc
4	1	1	3.4mm	>265g/²	2.7mm	>245g/m²
6	1	1	Binding wire diameter of 2.7m		Binding wire diameter of 2.0m
